PROJECT NAME: | SCRIPPS/XIMED | |||||||||||||||||||||||||||
| LOCATION: | SCRIPPS MEMORIAL HOSPITAL COMPOUND (OFF GENESEE), LA JOLLA CA 92037 | ||||||||||||||||||||||||||||
| CLIENT: | THIS WAS THE LAST PROJECT THAT AMAD DOUDAR DESIGNED WHILST EMPLOYED WITH B.S.H.A. | ||||||||||||||||||||||||||||
| DESCRIPTION: |
TEN STORY MEDICAL OFFICE BUILDING,
ARCHITECTURALLY DESIGNED TO LOOK LIKE FOUR STORY BUILDING IN ORDER TO BE COMPATIBLE WITH OTHER SURROUNDING HOSPITAL BUILDINGS. CONCRETE TOPPING FLOORS ON COMPOSITE METAL DECKS ON COMPOSITE STEEL BEAMS WITH RIGID MOMENT AND BRACED STEEL FRAMES ON DRILLED CAISSON FOUNDATIONS.
ADJACENT AND CONNECTED TO IT, IS A FIVE STORY PARKING STRUCTURE WITH A BASEMENT, ARCHITECTURALLY DESIGNED TO APPEAR AS AN INHABITABLE BUILDING. CONCRETE TOPPING FLOORS ON 50' SPAN DOUBLE-TEES ON PRE-CAST CONCRETE STRUCTURE WITH CAST IN PLACE CONCRETE SHEAR WALLS. |
||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||
 More Photos |
PROJECT NAME: | HOUSE 2 HOME (FORMER "HOME BASE") (91031) | |||||||||||||||||||||||||||
| LOCATION: | 1725 HACIENDA DR, VISTA CA 92083 | ||||||||||||||||||||||||||||
| CLIENT: | ERIC DAVY ARCHITECTS, SAN DIEGO CA | ||||||||||||||||||||||||||||
| DESCRIPTION: | 100,000 SQ.FT. SINGLE STORY CONCRETE TILT-UP BUILDING; 8' PANELIZED ROOF USING 50' SPAN OPEN WEB GANG-NAILED TRUSS PURLINS. | ||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||
More Photos |
PROJECT NAME: | BIG O TIRES (93006) | |||||||||||||||||||||||||||
| LOCATION: | 40525 WINCHESTER RD, TEMECULA CA 92590 | ||||||||||||||||||||||||||||
| CLIENT: | ERNEST M MANDEL ARCHITECTS, SAN DIEGO CA | ||||||||||||||||||||||||||||
| DESCRIPTION: | 6000 SQ.FT SINGLE STORY WOOD FRAME MECHANIC REPAIR SHOP. AT THE OPEN FRONT END, A STEEL RIGID MOMENT FRAME WAS USED. SPECIAL DESIGN ACCOMMODATED ASSEMBLY OF STEEL FRAME WITHOUT THE NEED FOR FIELD WELDING. | ||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||
 More Photos |
PROJECT NAME: | CHALDEAN SENIOR CITIZEN CENTER (95018) | |||||||||||||||||||||||||||
| LOCATION: | 1515 JAMACHA WAY, SAN DIEGO CA 92019 | ||||||||||||||||||||||||||||
| CLIENT: | MILTON H CREEK ARCHITECT, SAN DIEGO CA | ||||||||||||||||||||||||||||
| DESCRIPTION: | 24,000 SQ.FT. TWO STORY WOOD FRAME BUILDING WITH PRE-FABRICATED GANG-NAIL ROOF TRUSSES AND PRE-FABRICATED TRUSSED FLOOR JOISTS OVER A PARTIAL SUB-TERRANEAN 7,000 SQ.FT. PARKING BASEMENT WITH CONCRETE DECK, CONCRETE COLUMNS & MASONRY WALLS. | ||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||
 More Photos |
PROJECT NAME: | STARBUCK'S COFFEE (97027) | |||||||||||||||||||||||||||
| LOCATION: | 2924 CARLSBAD BLVD, CARLSBAD CA 92008 | ||||||||||||||||||||||||||||
| CLIENT: | STERLING DEVELOPMENT, SAN DIEGO CA | ||||||||||||||||||||||||||||
| DESCRIPTION: | EXISTING 1960'S SINGLE STORY 1,500 SQ.FT. BLDG W/ 9'HIGH WOOD ROOF; 12' HIGH HOLLOW CMU PARAPET WALLS; SLAB ON GRADE FOUNDATION. PROPOSED REMODELING INCLUDE NEW 12' HIGH ROOF, TWO NEW MANSARD TOWERS, NEW STOREFRONT. | ||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||
 More Photos |
PROJECT NAME: | SEARS (97038) | |||||||||||||||||||||||||||
| LOCATION: | 220 ROTANZI ST, RAMONA CA 92065 | ||||||||||||||||||||||||||||
| CLIENT: | RULAND DEVELOPMENT, SAN DIEGO CA. | ||||||||||||||||||||||||||||
| DESCRIPTION: |
NEW 8,000 SQ.FT. SINGLE STORY RETAIL, WOOD FRAME BLDG (WITH PRE-ENGINEERED WOOD ROOF TRUSSES), CONVENTIONAL SHALLOW FOOTINGS. LOADING DOCK. MONUMENT SIGN. TOWER & CANOPY. ROOF MOUNTED MECHANICAL PLATFORM. |
||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||
|
PROJECT NAME: | AERO PLACE OFFICE BLDGS (97063) | |||||||||||||||||||||||||||
| LOCATION: | 8291 & 8295 AERO PL, SAN DIEGO CA 92123 | ||||||||||||||||||||||||||||
| CLIENT: | NOGLE ONUFER ARCHITECTS, SAN DIEGO CA | ||||||||||||||||||||||||||||
| DESCRIPTION: |
DESCRIPTION : TWO SINGLE STORY, 24' HIGH, CONCRETE TILT-UP OFFICE/WAREHOUSE BUILDINGS. RELATIVELY FLAT PADS, PANELIZED WOOD FRAME ROOF, CONVENTIONAL SHALLOW FOOTINGS. BLDG "A" IS APPROX 36,000 SQ.FT. BLDG "B" IS APPROX 31,000 SQ.FT. WOOD TOWERS OVER THE PANELS. EACH END OF EACH BLDG IS HEAVILY GLAZED (POSSIBLY STEEL FRAME STRUCTURE - NO CONC TILT-UP). |
||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||
 More Photos |
PROJECT NAME: | INDUSTRIAL LOT 65 (98009) | |||||||||||||||||||||||||||
| LOCATION: | CARLSBAD, SAN DIEGO COUNTY, CALIFORNIA | ||||||||||||||||||||||||||||
| CLIENT: | NOGLE ONUFER ARCHITECTS, SAN DIEGO CA | ||||||||||||||||||||||||||||
| DESCRIPTION: |
THREE SINGLE STORY, 28' HIGH, CONCRETE TILT-UP OFFICE/WAREHOUSE BUILDINGS. SLIGHTLY SLOPING LOT; WHOLE BLDG WILL SLOPE 0.5% WITH DIRECTION OF GRADE; VERTICAL ELEMENTS THUS WOULD BE 0.5% OUT OF PLUMB; "HYBRID" ROOF SYSTEM; CONVENTIONAL SHALLOW FOOTINGS; BLDGS WILL . BLDG "I" IS 36,531 SQ.FT. BLDGS "II" IS 35,471 SQ.FT. & BLDG "III" IS 29,586 SQ.FT. |
||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||
 More Photos |
PROJECT NAME: | OTAY MESA SELF STORAGE BUILDINGS (99029) | |||||||||||||||||||||||||||
| LOCATION: | 6630 CAMINO MAQUILADORA, SAN DIEGO CA 92154 | ||||||||||||||||||||||||||||
| CLIENT: | LAURENCE WINTERS ARCHITECT, GRANTS PASS OR | ||||||||||||||||||||||||||||
| DESCRIPTION: |
FOUR-TWO STORY BLDGS, 108,000 SQ.FT., CMU WALLS / WOOD FRAME FLOORS, FLAT BUILT-UP ROOF WITH SOME MANSARDS, FEW TOWERS, SLAB ON GRADE, FLAT LOT, SHALLOW FOUNDATION. |
||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||
|
PROJECT NAME: | MARRIOTT - COURTYARD (99045) | |||||||||||||||||||||||||||
| LOCATION: | RANCHO BERNARDO, SAN DIEGO COUNTY, CALIFORNIA | ||||||||||||||||||||||||||||
| CLIENT: | NOGLE ONUFER ARCHITECTS, SAN DIEGO CA | ||||||||||||||||||||||||||||
| DESCRIPTION: |
3 STORY WOOD FRAMED STRUCTURE; PARTLY OVER GRADE AND PARTLY OVER SUB-TERRANEAN PARKING STRUCTURE. BUILT-UP FLAT ROOF W/ SOME MANSARD; CONC TOPPING OVER TJI FRAMED FLOORS; TWO WAY CONVENTIONAL CONCRETE SLAB OVER PARKING; CONVENTIONAL SHALLOW FOUNDATIONS. APPROX SQ.FT. : 100,000 GUEST UNITS, 14,000 LOBBY, 34,000 SUB-TERRANEAN PARKING. |
||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||
 More Photos |
PROJECT NAME: | RAMONA PLAZA OFFICE BLDG (99046) | |||||||||||||||||||||||||||
| LOCATION: | 11TH ST/MAIN ST, RAMONA CA 92065 | ||||||||||||||||||||||||||||
| CLIENT: | R A BURCH CONTRACTING, RAMONA CA | ||||||||||||||||||||||||||||
| DESCRIPTION: |
15,200 SQ.FT. TWO STACKING SORIES; FLAT ROOF; TRUSS JOISTS FLR; CONVENTIONAL SLAB/FOOTINGS; LEVEL LOT; STEEL SEISMIC FRAMES. |
||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||
 More Photos |
PROJECT NAME: | BUSH RESIDENCE (99012) | |||||||||||||||||||||||||||
| LOCATION: | ROYAL CREST COURT, ESCONDIDO CA | ||||||||||||||||||||||||||||
| CLIENT: | ALLEN CRUTCHER, CARDIFF-BY-THE-SEA CA | ||||||||||||||||||||||||||||
| DESCRIPTION: |
APPROX 5,500 SQ.FT. (INCLUDING GARAGE) SINGLE FAMILY RESIDENCE AS COMPREHENSIVELY DESCRIBED IN YOUR LETTER DATED NOV 13TH,1998. ASSUME SHALLOW CONVENTIONAL FOOTINGS. INCLUDE SITE RETAINING WALLS. |
||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||
 More Photos |
PROJECT NAME: | SILVERWOOD RESIDENCE (99113) | |||||||||||||||||||||||||||
| LOCATION: | 5816 WINLAND HILLS DR, RANCHO SANTA FE CA 92067 | ||||||||||||||||||||||||||||
| CLIENT: | WAYNE DAVIS, SAN DIEGO CA | ||||||||||||||||||||||||||||
| DESCRIPTION: |
8,000 SQ.FT. SINGLE STORY, WOOD FRAME "BARN TYPE" BLDG; CONVENTIONAL FOOTINGS; GANG-NAILED WOOD TRUSS ROOF. |
||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||
|
PROJECT NAME: | JAMES CANYON TRACT HOMES (00019) | |||||||||||||||||||||||||||
| LOCATION: | CARLSBAD, SAN DIEGO COUNTY CA | ||||||||||||||||||||||||||||
| CLIENT: | HALLMARK COMMUNITIES, DEL MAR CA | ||||||||||||||||||||||||||||
| DESCRIPTION: |
12 LOT SUB-DIVISION; 3 PLANS; WITH OPTIONS AS PER DWG SET DELIVERED TODAY & PREPARED BY HANSEN ARCHITECTURE; SHALLOW CONVENTIONAL FOOTINGS. |
||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||
|
|
PROJECT NAME: | SANWA BANK (00090) | |||||||||||||||||||||||||||
| LOCATION: | ROWLAND HEIGHTS, LOS ANGELES COUNTY CA | ||||||||||||||||||||||||||||
| CLIENT: | NOGLE ONUFER ARCHITECTS, SAN DIEGO CA | ||||||||||||||||||||||||||||
| DESCRIPTION: |
APPROX 6,000 SQ.FT.; SINGLE STORY; TYPE V NON- RATED; WOOD/STEEL FRAME; SHALLOW CONV FTGS; OTHER SITE IMPROVEMENTS EXCLUDED. |
||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||
 More Photos |
PROJECT NAME: | MISSION COVE TRACT HOMES (00134) | |||||||||||||||||||||||||||
| LOCATION: | FALCON PL, SAN MARCOS CA 92069 | ||||||||||||||||||||||||||||
| CLIENT: | RILINGTON COMMUNITIES, SAN MARCOS CA | ||||||||||||||||||||||||||||
| DESCRIPTION: |
28 LOT SUB-DIVISION; 3 PLANS; WOOD FRAMED HOMES W/ POSSIBLE STEEL RIGID SEISMIC FRAME IN PLAN #1; PLAN #3 IS A PERMUTATION OF #1; PLAN #1 HAS 3 OTHER PERMUTATIONS/OPTIONS; FLAT PADS; SHALLOW CONVENTIONAL FTGS. |
||||||||||||||||||||||||||||
|
|
|||||||||||||||||||||||||||||
| |||||||||||||||||||||||||||||
